Electrical Characteristics | Nominal Voltage | 12.8V | |
Nominal Capacity | 300Ah | ||
Energy | 3840Wh | ||
Internal Resistance (AC) | ≤20mΩ | ||
Cycle Life | ＞4000 cycles @1C 100% DOD | ||
Months Self Discharge | ＜3% | ||
Efficiency of Charge | 100% @0.5C | ||
Efficiency of Discharge | 96~99% @0.5C | ||
Standard Charge | Charge Voltage | 14.6±0.2V | |
Charge Mode | 0.5C to 14.6V, then 14.6V, charge current to 0.02C (CC/CV) | ||
Charge Current | 100A | ||
Max. Charge Current | 100A | ||
Charge Cut-off Voltage | 14.6±0.2V | ||
Standard Discharge | Continuous Current | 100A | |
Max. Pulse Current | 200A (＜3s) | ||
Discharge Cut-off Voltage | 10V | ||
Environmental | Charge Temperature | 0℃ to 55℃ (32F to 131F) @60±25% Relative Humidity | |
Discharge Temperature | -20℃ to 60℃ (-4F to 140F) @60±25% Relative Humidity | ||
Storage Temperature | -20℃ to 45 ℃ （-4F to 113F) @60±25% Relative Humidity | ||
IP Class | IP65 | ||
Mechanical | Plastic Case | ABS | |
Approx. Dimensions | 522mm*228mm*2404mm | ||
Approx. Weight | 35kg | ||
Terminal | M8 |
